Powerful performance for various vehicles

The REQUAL REQ1010 scissor lift is designed to support a wide range of vehicles. With an impressive lifting capacity of 3 tons, this lift effortlessly raises cars weighing up to 3000 kg. The minimum lifting height of 110 mm and a maximum lifting height of 1900 mm provide the flexibility you need for a variety of maintenance tasks.

Advanced hydraulic technology

Equipped with four hydraulic cylinders, the REQ1010 guarantees smooth and reliable operation. These cylinders work together with mechanical safety features and a pneumatic safety lock to ensure a safe working environment. The horizontal locking of the drive-on plates allows the platforms to be extended, offering extra flexibility for larger vehicles.

Technical specifications

• Lifting capacity: 3000 kg
• Lifting height: 1900 mm
• Initial platform height: 110 mm
• Platform length: 1450-2050 mm
• Platform width: 650 mm
• Lifting time: ≤55 s
• Lowering time: ≤55 s
• Total bridge length: 2045 mm
• Total bridge width: 2020 mm (635+750+635 mm)
• Power supply: 3x400V
• Total power: 2.2 kW
• Hydraulic oil: 16 L
• Air pressure: 6-8 kg/cm²
• Noise level: < 70 dB

Safety and compliance

The REQ1010 complies with the European Directive 2006/42/EC and the harmonized standards EN1493:2010 and EN60204-1:2006+A1:2009. This means you are investing in a product that meets the highest safety and quality standards. In addition, the lift comes with a CE certificate, offering extra peace of mind.

Including accessories and certification

With the REQ1010 you receive four rubber blocks of 160x120x40 mm and four of 180x120x95 mm, providing extra stability and protection during lifting. The ACEG certification is also included, meaning the lift meets Belgian safety regulations. Please note: this lift can only be sold and installed in Belgium.

Efficiency and ease of use

With a lifting and lowering time of ≤55 seconds, the REQ1010 increases efficiency in your workshop. The horizontal locking of the drive-on plates allows the platforms to be extended, offering extra flexibility for larger vehicles. The combination of powerful performance, advanced technology, and extensive safety features makes the REQUAL REQ1010 scissor lift an indispensable addition to any professional garage.
