High-quality copper core for optimal conductivity

The 50mm² battery cable is equipped with a solid copper core, ensuring excellent conduction of electric current. Copper is known for its superior conductive properties, minimizing energy loss and increasing the efficiency of your electrical system.

Durable PVC insulation for extra protection

This cable features a robust PVC insulation sheath that provides double protection against external influences. The insulation is resistant to oil and other chemicals, significantly extending the cable's lifespan. Additionally, the flexibility of the PVC sheath makes the cable easy to install, even in tight spaces.

Technical specifications

• Color: Red
• Wire cross-section: 50mm²
• Outer diameter: Ø 15.0 mm
• Maximum current: 355A at temperatures below 25°C
• Length: Available per running meter

Versatile applications in vehicles

Thanks to its flexibility and robustness, this battery cable is ideal for various applications within vehicles. Whether connecting the battery, linking electrical components, or providing power throughout the vehicle, this cable offers the reliability you need.

Calculating the correct cable thickness

It is essential to choose the correct cable thickness for your specific application. A general formula to calculate the required cable cross-section is:

Current (Amps) x distance (meters) x 0.2 = cable cross-section in mm²

For example:

• For a battery charger of 30 Amps at a distance of 2.5 meters: 30 x 2.5 x 0.2 = 15 mm². Since 15 mm² is not a standard size, choose the next available size, in this case 16 mm².

• For an inverter of 450 Watts on a 12 Volt battery, at a distance of 3 meters: 450 W / 12 V = 37.5 Amps. Then: 37.5 x 3 x 0.2 = 22.5 mm². The closest standard size is then 25 mm².

By applying these calculations, you ensure that you use the correct cable thickness for safe and efficient operation of your electrical systems.
