Reliable electrical connections for demanding applications

The TE Connectivity AMP Superseal 1.5 6-pin female connector is designed to meet the high demands of modern electrical systems. This connector offers a secure and waterproof connection, ideal for applications in the automotive, marine, and industrial sectors.

Excellent resistance to environmental influences

This connector withstands various environmental factors:

• Waterproof : Complies with the IP67 standard, meaning the connector is completely dustproof and protected against temporary immersion in water.
• Temperature range : Operates reliably at temperatures from -40°C to +125°C.
• Chemical resistance : Resists exposure to ozone, salt, gasoline, diesel, brake fluid, engine oil, and other corrosive substances.

Technical specifications

• Number of positions : 6
• Rated voltage : 24V
• Rated current : 14A
• Housing material : Glass-filled polyamide 6.6
• Mating tab width : 1.5 mm

Application areas

This connector is suitable for various applications, including:

• Automotive : Sensors, lighting, ECU connections.
• Marine : Electrical systems on boats and ships.
• Industrial machines : Connections in heavy machinery and equipment.

Installation and compatibility

The AMP Superseal 1.5 series is designed for easy installation and compatibility with other components from the same series. The connector features a secondary locking system that ensures correct and complete placement of the contacts, increasing the reliability of the connection.

Advantages at a glance

• Waterproof and dustproof : Suitable for use in humid and dusty environments.
• Wide temperature range : Reliable performance under extreme temperatures.
• Chemical resistance : Long-lasting durability when exposed to various chemicals.
• Easy installation : Designed for quick and secure assembly.

Summary

The TE Connectivity AMP Superseal 1.5 6-pin female connector offers a robust and reliable solution for electrical connections in demanding environments. With its excellent resistance to water, dust, temperature, and chemicals, this connector is an ideal choice for professionals seeking quality and durability in their electrical systems.
