Reliable 6-pin male connector for robust electrical connections in vehicles.
Robust and Reliable Connections
The DEUTSCH WIG DT series 6-pin male connector is designed for applications where reliability and durability are essential. This connector provides a strong and secure connection for various electrical systems in vehicles.
High-Quality Materials
The housing is made from thermoplastic material, ensuring high resistance to impact and extreme temperatures. This makes the connector suitable for use in demanding environments.
Excellent Protection Rating
With an IP68 rating, this connector is completely dust- and waterproof. This guarantees optimal performance even under harsh conditions such as exposure to moisture and dirt.
Electrical Specifications
- Rated current: 13 A per contact
- Rated voltage: 1500 V/AC
- Suitable wire size: 0.5 - 2 mm² (AWG 20 - 14)
Easy Installation
The integrated snap-lock mechanism ensures quick and secure coupling. The wedgelocks firmly secure the contacts in place, increasing the reliability of the connection.
Applications
This 6-pin male connector is ideal for:
- Lighting: Connecting headlights, taillights, and other lighting components.
- Sensors: Connecting various sensors within the vehicle.
- Other electrical systems: Suitable for various other electrical applications in vehicles.
Temperature Range
The connector operates reliably within a temperature range of -55°C to +125°C, making it suitable for use in a wide range of climatic conditions.
Dimensions
- Length: 30.94 mm
- Height: 22.63 mm
- Width: 18.19 mm
Compatibility
This connector is compatible with the DEUTSCH DT series and can be easily integrated into existing systems that use this series of connectors.
Accessories
For a complete installation, the following accessories are available:
- Wedgelocks: For locking the contacts.
- Back shells and boots: For extra protection against environmental influences.
- Mounting clips: For securely fastening the connector in the vehicle.
With the DEUTSCH WIG DT series 6-pin male connector, you are assured of a reliable and durable electrical connection in your vehicle.
Specifications
