Application and use

These yellow male round cable lugs of 5.0mm are ideal for safely and efficiently connecting electrical cables in various applications. They are suitable for cables with a cross-section of 4.0 to 6.0 mm², making them versatile for both automotive and industrial environments.

Technical specifications

• Type: Male round cable lug
• Color: Yellow
• Suitable for cable cross-section: 4.0 - 6.0 mm²
• Pin diameter: 5.0 mm
• Insulation material: PVC
• Maximum current: 26 to 40 A
• Temperature range: -40°C to +75°C

Benefits of these cable lugs

• Reliable connection: The cable lugs are made of tinned copper, ensuring excellent electrical conductivity and corrosion resistance.
• Easy installation: Thanks to the PVC insulation and correct dimensions, these cable lugs are easy to crimp with a suitable crimping tool.
• Safety: The insulation provides extra protection against short circuits and increases the safety of the electrical connections.

Areas of application

These cable lugs are suitable for:

• Automotive sector: For connecting electrical components in cars.
• Industrial installations: For connecting wiring in machines and equipment.
• Household appliances: For repairs and installations where reliable electrical connections are required.

Installation instructions

1. Strip the cable: Remove about 10 mm of insulation from the end of the cable.
2. Place the cable lug: Slide the cable lug over the stripped part of the cable.
3. Crimp the connection: Use a suitable crimping tool to securely attach the cable lug to the cable.
4. Check the connection: Make sure the cable is firmly attached and no exposed wires are visible.

Packaging

This set contains 5 yellow male round cable lugs of 5.0mm, packed in a convenient package for easy use and storage.
