Powerful and reliable make relay for vehicles

This high power make relay of 12V and 70A is designed to efficiently switch heavy electrical loads in vehicles. Thanks to its robust construction and high current capacity, it is ideal for applications such as lighting, pumps, and other powerful accessories.

Specifications and features

• Voltage: 12 Volt
• Current capacity: 70 Ampere
• Contact type: SPST (normally open)
• Housing dimensions: 28 x 28 x 25 mm
• Connections: 2 x 6.3 mm and 2 x 9.5 mm cable terminals
• Coil resistance: 80 Ohm
• Pull-in time: 10 ms
• Release time: 10 ms
• Operating temperature: -40°C to +85°C

Easy installation with metal mounting

The relay is equipped with a metal mounting bracket, ensuring a firm and secure installation in the vehicle. The standard connections make it compatible with common cable terminals and relay sockets, simplifying installation.

Applications in various vehicles

This relay is suitable for a wide range of vehicles, including cars, boats, and other vehicles with a 12V electrical system. It is ideal for switching:

• Lighting
• Electric pumps
• Fans
• Other powerful accessories

Durable and resistant to harsh conditions

With an operating temperature range of -40°C to +85°C and a robust housing, this relay is designed to operate reliably under various conditions. The high current capacity of 70A ensures the relay can handle heavy loads without performance loss.

Compatibility and connection options

The relay features four connection pins: two for the coil (6.3 mm) and two for the switching contact (9.5 mm). This configuration makes it compatible with standard relay sockets and cable terminals, facilitating integration into existing electrical systems.

Technical data

• Coil voltage: 12V DC
• Coil resistance: 80 Ohm
• Switching voltage: Maximum 14V DC
• Switching current: Maximum 70A
• Pull-in time: 10 ms
• Release time: 10 ms
• Operating temperature: -40°C to +85°C
• Housing dimensions: 28 x 28 x 25 mm
• Connections: 2 x 6.3 mm and 2 x 9.5 mm cable terminals

Summary

This high power make relay of 12V and 70A with metal mounting offers a reliable and efficient solution for switching heavy electrical loads in vehicles. Thanks to its robust construction, easy installation, and broad compatibility, it is an excellent choice for various applications.
