Powerful and reliable 24V 40A make relay

This high power make relay is designed for 24V systems and can switch currents up to 40A. Thanks to its robust construction and high-quality materials, it is ideal for various automotive applications.

Easy installation with metal mounting

The relay is equipped with a metal mounting bracket, ensuring a secure and safe installation in your vehicle. The standard dimensions make it compatible with common relay sockets and connections.

Technical specifications

• Nominal voltage: 24V DC
• Switching current: 40A
• Contact configuration: 1x make contact (SPST-NO)
• Housing: ABS plastic
• Connections: 4-pin (6.3 x 0.8 mm)
• Dimensions: 26.5 x 26.5 x 23.5 mm

Applications

This relay is suitable for various applications in vehicles, such as:

• Lighting: Switching additional lights or work lamps.
• Heating: Controlling heating systems.
• Pumps: Controlling fuel or water pumps.

Durability and performance

With a mechanical lifespan of 10,000,000 operations and an electrical lifespan of 100,000 operations, this relay offers long-lasting performance. It withstands temperatures from -55°C to +70°C, making it suitable for use in a wide range of environments.

Compatibility

This relay is compatible with various vehicles and devices equipped with a 24V DC power source. The standard dimensions and connections ensure easy integration into existing systems.

Quality guarantee

The relay complies with REACH and RoHS guidelines, meaning it is free from harmful substances and meets European standards for environmental protection and safety.
