Robust 9-pin relay socket for heavy-duty relays

This 9-pin relay socket is specially designed for heavy-duty relays and other devices of a similar size. The connections include:

• 4 x 2.8 mm (at the corners)
• 3 x 6.3 mm
• 2 x 9.5 mm

Includes connection cable for easy installation

The relay socket comes with a connection cable, which greatly simplifies installation. This allows you to quickly and efficiently connect your relay without needing to purchase additional accessories.

Compatibility and linkability

This relay socket is compatible with various relays, such as the 268763 model. In addition, the socket can be linked with other models, including RELH45B and RELH003B, offering flexibility when setting up your switching system.

Compact dimensions and easy mounting

With dimensions of 38 x 33 x 46 mm, this relay socket is compact and fits easily into various installations. Mounting is simple thanks to the 6 mm mounting holes, allowing you to secure the socket firmly.

High-quality contacts for reliable connections

The relay socket comes with high-quality contacts:

• 3 x 6.3 mm contacts (3-2922/1T or equivalent)
• 2 x 9.5 x 1.2 mm contacts for wire of 4-6 mm²

Note: the 2.8 x 0.8 mm contacts are not included, but are rarely needed. If desired, these can be ordered separately (3-2923/1 or 3-2923/1T).

Suitable for various applications

This relay socket is ideal for use in different applications, including:

• Automotive installations
• Industrial switching systems
• Electrical control panels

Thanks to the robust construction and versatile connection options, this relay socket is a reliable choice for professionals seeking quality and ease of use.
