Powerful and versatile switch for your car

This 12V 20A LED switch with green illumination is designed for a wide range of applications in cars. Whether you want to control extra lighting, accessories, or other electrical components, this switch offers the reliability and performance you need.

Technical specifications

• Switching capacity: 20A at 12V DC
• Contact resistance: Maximum 35mΩ
• Insulation resistance: 100MΩ at 500V DC
• Dielectric strength: 1500V AC for 1 minute
• Operating temperature range: -25°C to +85°C
• Lifespan: 10,000 cycles
• Number of contacts: 3
• Number of positions: 2 (on/off)
• Switch color: Green
• Backlighting: Yes
• Mounting hole diameter: 12.2 mm
• Maximum panel thickness: 4 mm
• Mounting opening dimensions: 29 x 11.6 mm

Easy installation and use

Thanks to its compact design and standard dimensions, this switch is easy to install in the dashboard or other suitable locations in your car. The green LED indicator provides a clear visual confirmation of the switch status, enhancing user-friendliness.

Durability and reliability

With a lifespan of 10,000 cycles and a robust construction, this switch is built to operate reliably and for a long time, even under demanding conditions. The high insulation resistance and dielectric strength ensure safe and stable performance.

Application possibilities

This switch is ideal for controlling various electrical accessories in your car, such as:

• Extra lighting
• Audio equipment
• Fans
• Other 12V electrical systems

Compatibility and versatility

The switch is suitable for use in various vehicles, including cars, boats, motorhomes, and caravans. The green LED illumination not only provides functionality but also adds aesthetic value to your vehicle's interior.

Safety and compliance

The switch meets relevant safety standards and is designed to operate safely within the specified electrical and thermal limits. The high insulation resistance and dielectric strength contribute to the safe operation of the device.

Summary

With its robust specifications, easy installation, and versatile application possibilities, this 12V 20A LED switch with green illumination is an excellent choice for controlling electrical accessories in your car. The combination of functionality, reliability, and aesthetics makes it a valuable addition to your vehicle.
