Robust hex bolt for strong connections

This hex bolt is made from high-quality Grade 5 steel, ensuring excellent strength and durability. The electroplated zinc coating provides an extra layer of protection against corrosion, making the bolt suitable for various applications, both indoors and outdoors.

Specifications

• Diameter : 5/8 inch (15.8 mm)
• Length : 6 inch (152 mm)
• Thread type : Unified National Coarse (UNC) with 11 threads per inch
• Wrench size : 15/16 inch (24 mm)
• Head height : 25/64 inch (9.9 mm)

Applications

This hex bolt is ideal for use in the automotive sector, machine construction, and other industrial applications where strong and reliable fastenings are required. Thanks to the UNC thread, the bolt is compatible with a wide range of nuts and other fasteners.

Advantages of electroplating

• Corrosion protection : The zinc layer protects the steel from rust and extends the lifespan of the bolt.
• Aesthetically pleasing : The shiny finish provides a neat and professional appearance.

Installation and use

For optimal fastening, it is recommended to tighten the bolt with a torque wrench to achieve the correct tension without damaging the material. Make sure to combine the bolt with a suitable nut and washer for a safe and stable connection.

Quality standards

This hex bolt meets the ASME B18.2.1 standard and is manufactured according to SAE J429 specifications, ensuring consistency and reliability in performance.

Availability

The hex bolt is available in various lengths and finishes to meet different needs. Refer to the product page for more information on available variants and specifications.
