Product description

These pan head self-drilling screws are manufactured according to the DIN 7504N standard and have a size of 3.5x19 mm. They feature a Torx TX15 drive and a zinc-plated finish, providing increased corrosion resistance.

Applications

These self-drilling screws are ideal for fastening sheet metal up to a thickness of 3 mm, without the need for pre-drilling. They are suitable for use in materials such as:

• Steel
• Iron
• Aluminum

Technical specifications

• Diameter: 3.5 mm
• Length: 19 mm
• Head diameter: 6.9 mm
• Drive: Torx TX15
• Drilling capacity: up to 3 mm thickness
• Material: Hardened steel, zinc-plated
• Standard: DIN 7504N

Advantages

• Efficiency: Thanks to the self-drilling tip, pre-drilling is unnecessary, saving time during installation.
• Durability: The zinc-plated finish offers increased protection against corrosion.
• Ease of use: The Torx TX15 drive provides better grip and reduces the risk of slipping during screwing.

Packaging

These self-drilling screws are supplied in sets of 20 pieces, conveniently packaged for both professional and private use.

Important note

For this type of screw, the length is measured excluding the screw head.
