Reliable connection for pneumatic systems

This L-shaped plastic air coupling is designed to efficiently and safely connect 4 mm pneumatic hoses. Thanks to its thoughtful design and high-quality materials, this coupling offers a reliable solution for various applications.

High-quality materials for durability

The coupling is made from a combination of nickel-plated brass and PA 66 plastic, ensuring a robust and corrosion-resistant construction. The stainless steel (SS) toothed ring guarantees a firm grip on the hose, while the NBR O-ring provides optimal sealing.

Easy installation and use

The push-in design allows for quick and easy installation without extra tools. By pressing the release ring, the hose can be effortlessly disconnected, making maintenance and adjustments easier.

Suitable for various applications

With a maximum working pressure of -0.95 to +20 bar and a temperature range of -20°C to +80°C, this coupling is suitable for a wide range of pneumatic applications, both in industrial environments and the automotive sector.

Specifications

• Type: L-shaped push-in coupling
• Hose diameter: 4 mm
• Maximum working pressure: -0.95 to +20 bar
• Temperature range: -20°C to +80°C
• Housing material: Nickel-plated brass/PA 66
• Release ring material: PA 66
• Toothed ring material: SS
• Sealing material: NBR

Key benefits

• Quick installation: No tools needed thanks to the push-in design.
• Durable: High-quality materials ensure a long lifespan.
• Versatile: Suitable for various pneumatic applications.
• Easy maintenance: Hoses can be easily disconnected for maintenance or adjustments.

Application areas

This L-shaped air coupling is ideal for use in:

• Pneumatic systems in the automotive sector
• Industrial automation
• Air tools and equipment
• Other applications where reliable hose connections are required

With this plastic air coupling, you ensure an efficient and reliable connection in your pneumatic systems.
