Reliable connection for pneumatic systems

This plastic push-in coupling is designed to provide a strong and leak-free connection between pneumatic hoses and components. Thanks to the combination of a special O-ring and locking ring, the hose remains securely in place, while the O-ring ensures optimal sealing.

Easy installation and maintenance

The push-in design allows for quick, tool-free installation. By pressing the release ring, the hose can be easily disconnected, making maintenance and any adjustments easier.

High-quality materials for durability

• Body: Nickel-plated brass/PA 66
• Release ring: PA 66
• Locking ring: Stainless steel
• Seal: NBR

These materials ensure a long service life and resistance to corrosion and wear.

Suitable for various applications

With a maximum working pressure of -0.95 to +20 bar and a temperature range of -10°C to +80°C, this coupling is suitable for a wide range of pneumatic applications in both industrial and automotive environments.

Specifications

• Type: Straight
• Hose diameter: 6 mm
• External thread: 1/8"
• Maximum working pressure: -0.95 to +20 bar
• Temperature range: -10°C to +80°C

Compatibility and versatility

This coupling is compatible with nylon or polyurethane hoses and can be used in systems with oiled or unoiled compressed air, as well as water. This makes it a versatile choice for different applications.

Quality guarantee

The coupling complies with RoHS guidelines and is manufactured with silicone-free U-seals, contributing to reliable and safe operation in various environments.
