Applications and usage

This single-core PVC cable of 2.0mm² is designed for various electrical applications in cars. Thanks to its flexible construction, the cable is easy to install, even in tight spaces. The red color makes it easy to identify and distinguish circuits.

Technical specifications

• Cable thickness: 2.0mm²
• Nominal construction: 40 x 0.25mm
• Maximum resistance: 9.42 Ohm/km
• Outer cable diameter: 2.50 - 2.60mm
• Minimum insulation thickness: 0.30mm
• Insulation material: PVC compound T2 according to Fiat 91107/18
• Insulation hardness: 95±5 shore A
• Maximum voltage: 300V
• Temperature range: -30ºC to +105ºC
• Standards: ISO6722:2002 / DIN 72551/6 / EEC directive 2000/53 / FIAT 91107/18

Durability and reliability

The cable is manufactured with high-quality materials that ensure a long lifespan and reliable performance. The PVC insulation provides protection against wear and external influences, which is essential for automotive applications.

Easy installation

The flexibility of this cable makes installation easy, even in complex wiring. The compact 8-meter mini roll is convenient for both small and larger projects, without excess material.

Versatility

This cable is suitable for various applications, including:

• Connecting switches and relays
• Connecting lighting systems
• Repair and maintenance of existing wiring

Quality guarantee

Manufactured according to strict industrial standards, this cable offers the assurance of quality and safety for all your automotive electrical installations.
